Making cement is an energy-intensive process. In a cement plant, the electrical energy load can reach up to 25 MW, consuming 185 million kilowatt hours of electricity annually. In addition, the plant consumes a large amount of coal and natural gas. CalPortland is an enormous producer of cement, concrete, aggregates and asphalt. With 80 facilities spanning five states across the western U.S., one might logically assume that CalPortland consumes a lot of energy.
While that may be true, that does not mean the cement-making giant is ignorant of its energy consumption. Quite the contrary in fact, as CalPortland was recognized in April by the Environmental Protection Agency (EPA) with an eleventh consecutive ENERGY STAR® Partner of the Year — Sustained Excellence Award. Of the many key accomplishments recognized by the EPA, CalPortland saved 29 billion British thermal units over 2013, and reduced its energy intensity by 16 percent since 2003.
To date, those energy savings have accumulated to \$73.1 million.
In contrast to CalPortland’s pyroprocessing, the company’s compressed air energy demand may seem diminutive — reaching 1 to 2 MW yearly in a given facility. Why then is compressed air a top 5 focus for the energy team at CalPortland? According to William Jerald, CEM, the Chief Energy Engineer at CalPortland, it’s because cognizance is key.
Bill Jerald, CEM, Chief Energy Engineer at CalPortland
“We’ve done literally hundreds of compressed air modifications, changes, upgrades, audits,” Jerald explained to us in a recent interview. “Compressed air is a huge part across the company. Once you understand that it’s energy-intense, it’s kind of easy to work on because you can do quick and easy upgrades and save energy right away.”
By generating awareness of the costs of compressed air, Jerald and his energy team have successfully driven those costs down. Fortunately, Jerald was kind enough to speak with the team at Compressed Air Best Practices® Magazine about the energy program at CalPortland. During our conversation, he discussed the history of the company’s energy program, how compressed air fits into their energy plans, and how partnering with ENERGY STAR has been a boon for the company’s energy initiatives.
The History of CalPortland’s Energy Program
CalPortland’s energy program got its official start in 2003. At the time, the company’s primary product was cement, and it had three cement plants along with a few ready-mix concrete plants in southern California. Having a small number of energy-intensive locations made it easier for CalPortland to “take the next step” with its energy program. A nudge from ENERGY STAR also helped.
“Really, it got its big kick-start from ENERGY STAR,” Jerald said. “They reached out to us — got in touch with the director of engineering, Steve Coppinger. It became a one-man wolf pack kind of party where Steve was pushing and directing it from the engineering department. It was not his full-time job, but he spent a lot of time on it. He got the executives to buy into it.”
In 2007, Jerald was working as the electrical supervisor at CalPortland’s cement plant in Arizona. That’s when he was asked to become the Energy Manager for the entire company.
CalPortland currently operates in Washington, Oregon, Nevada, California and Arizona. The company’s facilities include cement plants, cement terminals, ready-mix plants, asphalt plants, and aggregate mines. It is no easy feat to remain aware of — let alone manage — the energy use of such an expansive and diverse array of facilities. Nevertheless, Jerald is responsible for just that.
CalPortland’s cement plant in Rillito, AZ
“We’re probably in about 75 to 80 locations,” Jerald told us. “It’s hard for me to narrow down, because we’ve been broadening our territory quite a bit. It seems like every couple of weeks a new plant pops up on my grid that I never even knew about, and we have to start looking at their energy footprint.”
Active Corporate Participation
Jerald is not alone in his endeavor, as the energy management program at CalPortland has strong corporate backing. Where initially the energy team was a “one-man wolf pack” led from within the engineering department, it now has a steering committee comprising Steve Coppinger, who is now the VP of engineering services at CalPortland, along with several other VPs, engineers, and divisional managers who are assigned as the energy manager for their respective division.
The divisional managers have similar duties to that of Coppinger’s when the energy program just when the energy program just started. They have a role as an energy team member in addition to their primary duties.
“For each department or division in the company, we have a variety of managers who are assigned the role as the energy manager for their division,” Jerald explained. “It’s not their primary job, but it’s one of their side duties. Their positions within the company are various, but they are assigned the task of being an energy manager for that area. And then they work with me, and I work with them.”
A vital part of for the energy program is the active involvement of CalPortland’s CEO, Allen Hamblen, who regularly attends Jerald’s quarterly energy management meetings.
“This program keeps staying alive because I can call my CEO on a first-name basis,” Jerald said. “It’s like having a rock star come to your show. People will attend just because they want to hear what the CEO’s got to say. There’s not a lot of opportunity to get that on a day-to-day basis, so it helps my program get attendance just because they know he’s going to be there.”
The corporate backing is in no small part due to the monetary gains accrued through the energy management program. CalPortland’s annual energy spend is \$81 million — the highest operating cost of the company. That metric certainly helps get executive attention. If Jerald saves 1 percent in energy costs, that is \$800,000 that goes straight to the company’s bottom line.
“The number one reason is money,” Jerald said. “It’s about saving money and helping the health of our company.”
Energy Management Goes Viral
According to Jerald, the quarterly information-sharing meeting is “one of the big assets of the energy management program.” Using a videoconference system, all of the energy managers, engineers and corporate team members are able to attend. After an update from Hamblen, other executives discuss the importance of the energy program from their perspectives. Jerald follows these talks with an educational segment where he may share a recent project that yielded energy savings.
“When you’re doing that educational process, you’re sharing,” Jerald explained. “And when you share it across the energy managers, almost every time you see a guy or two taking a note. It’s like the YouTube viral process, where you share it, and then they go back and share it amongst their group. That sharing across the plants helps us out a lot.”
Obviously there is a lot more to energy management than simply sharing information, and Jerald makes it a priority to make himself available to all of the members of the energy team, along with the operations personnel that he works with regularly.
“I try to make myself very available so that they can call me,” Jerald said. “We look at rebates all the time. I get emails all the time saying, ‘Hey these are the three compressors, which one should I use?’ So it just grows like a viral process, and we make more and more changes.”
For Jerald, earning his co-workers’ trust is especially important for when he visits in person. There may be crews at a particular plant that have been working there for thirty years, and the only thing they know is what works.
“When you’re there to train them, some of them will say, ‘I have to have 155 psi — that’s the only way my plant runs,’” Jerald explained. “They’ve had plenty of engineers or someone from corporate come in and force something down their throat. So I walk in, explain my experience. (Jerald was an electrician in the Navy and worked in a cement plant for 15 years.) Once they’re comfortable that I’m not just a behind-the-desk guy, then they open up, and we start really pointing things out.
And over time, we’ve dropped plants from 155 psi to less than 110.”
Compressed Air at CalPortland
As previously mentioned, compressed air is not a large consumer of energy in comparison to CalPortland’s other applications, but it remains a major focus. Jerald helped to elucidate the compressed air consumption at CalPortland:
“It’s hard to quantify. With the cement plants, we’re talking about a 25 MW load. Compressed air at a cement plant is probably 1 or 2 MW — if that. But in the smaller facilities, it becomes a bigger component, a bigger load of the overall electrical. It’s definitely a top 5 focus — not necessarily a top 5 energy consumer.”
CalPortland uses compressed air in various ways throughout its network of operations. At just about every facility — from the ready-mix plants to the aggregate and mining facilities — cylinder operation for controlling gates and ramps is a key user of compressed air. In ready-mix plants and cement terminals, for instance, the cylindrically controlled gates and ramps fill trucks with sand, gravel and cement powder.
One of the largest compressed air consumers at CalPortland is an environmental application that takes place at the cement plants. Since there are limitations to the temperature of gases leaving an exhaust stack, the gases from the kiln must be cooled. To cool the exhaust effectively, water is sprayed into the air stream as it leaves the kiln. Compressed air is used to atomize the water, thereby maximizing the heat transfer and cooling the exhaust more efficiently. CalPortland has two 1000-hp compressors dedicated to this process at each of its cement plants.
CalPortland’s cement plant in Mojave, CA
Dust collection is another a major compressed air application at many of CalPortland’s facilities. In addition, there are also smaller applications like vibrators and automotive shop compressors that consume compressed air.
Cognizance is Key
Treasure hunts, or events that engage employees to help identify energy-saving opportunities, have been one of the most effective methods for Jerald and his energy management team — especially in regards to compressed air. The treasure hunts help promote awareness among plant personnel of the costs associated with compressed air.
“Compressed air is a utility to them,” Jerald told us. “You got some galvanized pipe, thread it together, and boom — I have a cylinder working. To put that energy knowledge in their brain, then the light goes off and they get it. They understand why I focus on it. Then it becomes easy.”
Jerald shared a great example of how simply being aware of the compressed air system can help save money — even though this particular example was more about fuel savings than electrical. One of CalPortland’s facilities had been leasing a diesel compressor for five years. Facility personnel constantly filled it up with fuel, unaware that there were better options. After Jerald and the plant’s staff identified the issue, bought a new compressor, and installed it, the payback was less than 6 months.
ENERGY STAR Support
While support from corporate certainly helps Jerald with his daunting task, he acknowledged that ENERGY STAR is another indispensable ally in his efforts to cut energy costs.
“ENERGY STAR really helps me out with their method of sharing practices,” Jerald explained. “All the stuff I get to use in my day-to-day work is fantastic for me, but the marketing, the ENERGY STAR logo, that label is so important because people recognize it as a good thing.”
With their latest award, CalPortland is now tied with 3M — a huge, multinational company — in ENERGY STAR awards, which is very significant for CalPortland. The positive marketing that comes along with the ENERGY STAR brand sheds a positive light on any company affiliated with it.
“I’m pretty passionate about the energy job. It’s very exciting for me, and the ENERGY STAR award is a tool that we use,” Jerald said. “It just gets attention. Even inside of our property, this logo is everywhere. It’s on doors, on walls, on signs, and people know about it.”
“I have two daughters, and they think I work for ENERGY STAR,” Jerald continued. “When they see an ENERGY STAR refrigerator, they say ‘hey dad, there’s your company.’ It’s just such a big part of my job that I’m always excited to talk about it.”
At the end of the day, if you are an energy manager and your children think that you work for ENERGY STAR, you are doing something right.
